 Technical Specifications |
| Interface |
Gigabit Ethernet |
| Connector |
Two VGA D type connectors
Two Ethernet RJ-45 connectors
One USB connector
One 5V DC power supply connector or Power-Over-Ethernet |
| VGA Signaling |
R,G,B plus separate HSYNC and VSYNC signals
R,G,B plus CSYNC signal
R,G,B with Sync-On-Green synchronization. |
| VGA Modes |
HSYNC rate is between 15KHz and 150KHz
Pixel rate is between 12MPixel/s and 270 MPixel/s for
noninterlaced grab
Pixel rate is between 270 MPixel/s and 532 MPixel/s for two |
| Supported Video Modes |
640×480 - 1600×1200 |
| Update Rate (over LAN) |
640×480 - 30-60 fps
1280×1024 - 15-60 fps
1600×1200 - 8-25 fps |
| Hardware Features |
Integrated Active VGA Splitter
Internal 2-port Ethernet Hub
On-board Lossless Compression |
| Dimensions |
7.95"×4.13"×1.38", 202×105×35 mm |
| Weight |
0.7 lb, 318 g |
|
|
