 Technical Specifications |
| RGB
Mode Support |
720×400 at 70Hz, 85Hz
640×480 at 60Hz, 70Hz, 72Hz, 75Hz, 85Hz
800×600 at 56Hz, 60Hz, 72Hz, 75Hz, 85Hz
1024×768 at 60Hz, 70Hz, 72Hz, 75Hz, 85Hz
1152×864 at 60Hz, 70Hz, 75Hz, 85Hz
1152×900 at 66Hz
1280×960 at 60Hz, 85Hz
1280×1024 at 60Hz, 70Hz, 85Hz, 85Hz
1600×1200 at 60Hz, 70Hz, 75Hz, 85Hz
|
| Scalability |
Up to 100 participants |
| Software
upgrade |
Yes |
| Frame
rate |
Up to 15 fps |
| Feedback
monitor |
Full screen optional |
| Compression |
H.264, Proprietary |
| Connectors |
DVI-I, VGA |
| Bandwidth |
400 kbs |
| Audio
Parameters |
3.5 mm jack, microphone level mono |
| Viewer
Application |
Quick Time, VLC, Java Applet |
| Operator's
Interface |
Epiphan Graphical Controller™,
Web Interface,
RS-232 (Crestron/AMX ready) |
| Special
Features |
No Moving Parts |
| Dimensions |
5.8" x.2.8" x 10.0"
148mm x 71mm x 254mm |
| Weight |
2.5kg / 5 lb |
|
|
