Input Connector

1 x BNC SMPTE 292M SMPTE 259M

Output Connector

6 x BNC SMPTE 292M SMPTE 259M

Data Rates

1485, 1483, 270, 143 Mbps

Equalization

up to 300m (1000 Feet)

Amplitude

with 800mV+-3% (<10%)

Rise Overshoot

less than 2% (<10%)

Fall Overshoot

less than 2% (<10%)

Long time jitter

0.195 ui (<1.0ui)

Timing jitter

0.195 ui (<1.0ui)

Alignment jitter

0.127 ui (<1.0ui)

Power Supply

5VDC

Operation Temperature

0℃ to 55℃
